LEDs

  • LED stands for Light Emitting Diode.
  • An LED is semiconductor device that emits light due to Electroluminescence effect.
  • LEDs are used in almost each electronical device as indicators.
PLCC 3528
PLCC 3528
PLCC 3528 Package(1.9T) Side-look LED
■ 3.5 mm X 2.8 mm SMD LED, 1.9 mm thickness
■ Ultra bright reflector type PLCC 2 LED
■ Suitable for all SMD assembly and solder process
■ Ideal for backlighting
■ EIA STD Package
■ RoHS compliant
Type Part No. Lighting Color Dominant Wavelegth
 (nm)		 Luminous Intensity
IV(Mcd) @IF=5/20mA		 Forward Voltage(v) Viewing Angle2
1/2
Typical Typical Min Max Typ
3528 L3528QRC Ultra Red 624 350 1.8 2.4 120
L3528QYOC Ultra Orange 604 350 1.8 2.4 120
L3528QYC Ultra Yellow 588 350 1.8 2.4 120
L3528QGC Ultra Yellow Green 572 150 1.8 2.4 120
L3528PGC Ultra Dark Green 560 45 1.8 2.4 120
L3528QBGC Ultra Green 518 1000 2.6 3.4 120
L3528QBC Ultra Blue 465 350 2.6 3.4 120
L3528QWD White X=0.29, Y=0.28 2200 2.6 3.4 120
L3528QWYD Warm White X=0.42, Y=0.43 2200 2.6 3.4 120
3528 BI-COLOR
(2COLOR)		 L3528QRQGC Ultra Red 624 300 1.8 2.4 120
L3528QRQGC Ultra Yellow Green 572 100 1.8 2.4 120
L3529QRQYC Ultra Red 624 300 1.8 2.4 120
L3529QRQYC Ultra Yellow  589 300 1.8 2.4 120
L3530QRQBC Ultra High Red 624 300 1.8 2.4 120
L3530QRQBC Ultra Blue 468 300 2.8 3.6 120
L3531QRQBGC Ultra High Red 624 300 1.8 2.4 120
L3531QRQBGC Ultra Green 525 800 2.8 3.6 120
L3532QBQBGC Ultra Blue 468 300 2.8 3.6 120
L3532QBQBGC Ultra Green 525 800 2.8 3.6 120
3528 FULL-COLOR
(1.9T)		 L3528QRQBGQBC Ultra Red 624 350 1.8 2.4 120
L3528QRQBGQBC Ultra Green 525 800 2.8 3.6 120
L3528QRQBGQBC Ultra Blue 468 300 2.8 3.6 120
